Shimano RT-6B750 Front Rotor
What the checker says32will not fit17check before you buy64worth knowing
Run variant by variant through the mountain bike builder’s own engine. Every sentence below is the checker’s, unedited. Nothing here says this part fits your bike; it says what it does and does not fit among the parts we hold.
Checked against 5997 verified mountain bike parts in this catalog. 5832 produced no finding of any kind; that is RT-6B750 200mm (6-bolt, Thick 2.2mm). RT-6B750 220mm (6-bolt, Thick 2.2mm) clears 5680. Each variant produces 12 to 22 distinct errors and 12 to 15 distinct warnings.
Will not fit
- Will not fiterror · Front WheelFront rotor: a 6-bolt rotor does not mount on a Center Lock front hub as it is - the two use different rotor interfaces. The part that bridges them is a Center Lock adapter, and the ones makers publish fit one-piece rotors only. A shim or adapter may make other sizes or standards work, but that is a modification, not a fit. On 61 of the 270 verified front wheels in this catalog. Applies to all 2 variants.
- Will not fiterror · Front HubFront rotor: a 6-bolt rotor does not mount on a Center Lock front hub as it is - the two use different rotor interfaces. The part that bridges them is a Center Lock adapter, and the ones makers publish fit one-piece rotors only. A shim or adapter may make other sizes or standards work, but that is a modification, not a fit. On 16 of the 40 verified front hubs in this catalog. Applies to all 2 variants.
Front brake rotor max, Front Brake. 25 more findings from the same check, on up to 1 of the 92 verified brakes each.
Front brake rotor excluded, Front Brake. 5 more findings from the same check, on up to 1 of the 92 verified brakes each.
Open a variant in the builder to see the ones that apply to your own parts.
Check before you buy
- Check before you buywarning · ForkFront rotor: 220mm exceeds the fork max of 203mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 115 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
- Check before you buywarning · ForkFront rotor: 200mm exceeds the fork max of 180mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 31 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
- Check before you buywarning · ForkFront rotor: 220mm exceeds the fork max of 180mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 31 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
- Check before you buywarning · ForkFront rotor: 220mm exceeds the fork max of 200mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 22 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
- Check before you buywarning · ForkFront rotor: 220mm exceeds the fork max of 205mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 9 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
- Check before you buywarning · ForkFront rotor: 200mm exceeds the fork max of 185mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 5 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
- Check before you buywarning · ForkFront rotor: 220mm exceeds the fork max of 185mm. A post-mount adapter is the part that steps a caliper up to a bigger rotor, sold in the maker’s own discrete size steps (commonly +20mm, e.g. 160 to 180mm or 180 to 200mm) rather than for any gap - and not every step is offered for every caliper model, so check the maker’s own fitment before buying. On 5 of the 490 verified forks in this catalog. Applies to 1 of 2 variants.
Front brake rotor thickness, Front Brake. 10 more findings from the same check, on up to 1 of the 92 verified brakes each.
Open a variant in the builder to see the ones that apply to your own parts.
Worth knowing
Front rotor interface unstated, Front Wheel. 58 more findings from the same check, on up to 1 of the 270 verified front wheels each.
Front rotor interface unstated, Front Hub. 6 more findings from the same check, on up to 1 of the 40 verified front hubs each.
Open a variant in the builder to see the ones that apply to your own parts.
$42.00 to $45.00 MSRP·234 to 267 g
What the maker states
- Size
- 200 mm rotor (on 1 of 2 variants); 220 mm rotor (on 1 of 2 variants)
- Mount
- 6-bolt
- Thickness
- 2.2 mm
A value shown as a set or a range differs between this model’s variants and is never one variant’s spec.
2 verified variants
| Variant | Size | Price (MSRP) | Weight | Source | Last checked | Build |
|---|---|---|---|---|---|---|
| RT-6B750 200mm (6-bolt, Thick 2.2mm) | 200 mm rotor | $42.00 | 234 g | maker’s page | 2026-08-15 | Build with this |
| RT-6B750 220mm (6-bolt, Thick 2.2mm) | 220 mm rotor | $45.00 | 267 g | maker’s page | 2026-08-15 | Build with this |
Source
Source: each variant links the maker’s own page in the table above. Last checked 2026-08-15.
Checked against
The checker ran this model against every verified part below that it has a slot for, the same way it checks a build in the builder. What follows is the verdict it actually produced for that specific pairing — not a recommendation, and not a guarantee any of these parts fits your own bike.
- 5DEV R-SPEC Trail/Enduro Cranks (Crankset) No conflicts found
- 9point8 Fall Line (Dropper Post) No conflicts found
- 9point8 Stout (31.8, 30mm) (Stem) No conflicts found
- ACID SLX 30 front (Front Wheel) Will not fit
- ACID SLX 30 rear (Rear Wheel) No conflicts found
- Acros ZS44/ZS56 (Headset) No conflicts found
6 of 1861 counterparts with a page of their own that the checker actually probed this model against, in alphabetical order by brand and model — never by price, popularity or the verdict itself.
