Shimano Ultegra Rear Wheel
What the checker says89will not fit20check before you buy
Run variant by variant through the road bike builder’s own engine. Every sentence below is the checker’s, unedited. Nothing here says this part fits your bike; it says what it does and does not fit among the parts we hold.
Checked against 948 verified road bike parts in this catalog. 875 produced no finding of any kind. Each variant produces 35 distinct errors and 8 distinct warnings.
Will not fit
- Will not fiterror · Rear RotorRear rotor: a 6-bolt rotor does not mount on a Center Lock hub as it is - the two use different rotor interfaces. The part that bridges them is a Center Lock adapter, and the ones makers publish fit one-piece rotors only. A shim or adapter may make other sizes or standards work, but that is a modification, not a fit. On 15 of the 38 verified rotors in this catalog. Applies to all 3 variants.
- Will not fiterror · Front WheelBrake system mismatch: Front wheel = rim, Rear wheel = disc. Disc and rim-brake parts do not mix on one build. On 7 of the 101 verified front wheels in this catalog. Applies to all 3 variants.
- Will not fiterror · Front CaliperBrake system mismatch: Rear wheel = disc, Front brake = rim. Disc and rim-brake parts do not mix on one build. On 6 of the 35 verified calipers in this catalog. Applies to all 3 variants.
- Will not fiterror · Rear CaliperBrake system mismatch: Rear wheel = disc, Rear brake = rim. Disc and rim-brake parts do not mix on one build. On 6 of the 35 verified calipers in this catalog. Applies to all 3 variants.
- Will not fiterror · Shifter/Brake LeversBrake system mismatch: Levers = rim, Rear wheel = disc. Disc and rim-brake parts do not mix on one build. On 3 of the 25 verified shifter/brake levers in this catalog. Applies to all 3 variants.
- Will not fiterror · Front TireWheel size mismatch: Rear wheel = 700c, Front tire = 650b. A road or gravel build runs one wheel size end to end. On 2 of the 79 verified tires in this catalog. Applies to all 3 variants.
- Will not fiterror · Rear TireWheel size mismatch: Rear wheel = 700c, Rear tire = 650b. A road or gravel build runs one wheel size end to end. On 2 of the 79 verified tires in this catalog. Applies to all 3 variants.
Rg freehub, Cassette. 81 more findings from the same check, on up to 1 of the 34 verified cassettes each.
Rg wheel size, Front Wheel. 1 more finding from the same check, on up to 1 of the 101 verified front wheels each.
Open a variant in the builder to see the ones that apply to your own parts.
Check before you buy
Rg tire rim, Rear Tire. 18 more findings from the same check, on up to 2 of the 79 verified tires each.
Rg tire rim min, Rear Tire. 2 more findings from the same check, on up to 1 of the 79 verified tires each.
Open a variant in the builder to see the ones that apply to your own parts.
$850.00 to $960.00 MSRP·831 to 911 g
What the maker states
- Wheel
- Built for a 700c wheel
- Freehub
- / driver hg-l2
- Rotor mount
- Center-lock
- Internal width
- Internal rim width 21 mm
- Hub
- Spacing 12x142
- Brake system
- Disc
3 verified variants
| Variant | Price (MSRP) | Weight | Source | Last checked | Build |
|---|---|---|---|---|---|
| Ultegra WH-R8170-C36-TL | $900.00 | 831 g | maker’s page | 2026-07-22 | Build with this |
| Ultegra WH-R8170-C50-TL | $850.00 | 872 g | maker’s page | 2026-08-15 | Build with this |
| Ultegra WH-R8170-C60-TL | $960.00 | 911 g | maker’s page | 2026-08-15 | Build with this |
The rest of what the maker states2 stated·1 not published
- Tire up to 32 mm (maker-stated maximum).
- Tire no narrower than 25 mm.
1 further field the checker looks for is not published by Shimano, so we leave it blank rather than estimate it, and that check stays silent on this rear wheel. It is maximum tire basis. Each is recorded as “not stated by the maker (not checked)”.
Source: each variant links the maker’s own page in the table above. Last checked 2026-07-22 to 2026-08-15.
Checked against
The checker ran this model against every verified part below that it has a slot for, the same way it checks a build in the builder. What follows is the verdict it actually produced for that specific pairing — not a recommendation, and not a guarantee any of these parts fits your own bike.
- 3T Aeroflux Integrale (Handlebar) No conflicts found
- 3T Apto Stealth Stem (Stem) No conflicts found
- 3T Superergo LTD (standard, non-INTEGRALE) (Handlebar) No conflicts found
- All-City Zig Zag Frameset (Frame) No conflicts found
- Argon 18 SUM D-Shape Seatpost (Seatpost) No conflicts found
- Argon 18 Sum Frameset (Frame) No conflicts found
6 of 625 counterparts with a page of their own that the checker actually probed this model against, in alphabetical order by brand and model — never by price, popularity or the verdict itself.
